| ブランド名: | UVIR |
| モデル番号: | THG100180 |
| MOQ: | 交渉可能 |
| 価格: | negotiable |
| 支払条件: | L/C、T/T、Western Union、MoneyGram |
| Attribute | Value |
|---|---|
| Material | Quartz tube |
| Coating | Gold |
| Warranty Time | 5000 Hours |
| Filament | Tungsten Wire |
| Power | 55-575V |
| Voltage | 200-6000W |
| Total length | 50-1500mm |
| Heating length | 50-1500mm |
Standard cross-section dimensions for industrial IR twin tubes in mm. The strength of quartz tubes is enhanced using a steel beam design concept, allowing lengths up to 6m (cross section: 33×14mm).
| Twin Tube Cross-Section | Maximum Length (m) | S-W | M-W |
|---|---|---|---|
| 8×18 | 2.1 | N | Y |
| 23×11 | 3.5 | Y | Y |
| 33×14 | 4.0 | Y | Y |
Heater dimensions depend on required voltage/wattage relationship.
| Type | Twin Tube Short Wave Halogen Infrared Heating Lamp |
|---|---|
| Size | 11×23mm |
| Coating | Gold |
| Power | 55-575V |
| Voltage | 200-6000W |
| OEM/ODM | Custom voltage, wattage, length, base, cables, and universal burning position available |
| Voltage (V) | Wattage (W) | Twin Tube | Total Length | Heated Length | Design Type | Gold | White | Clear |
|---|---|---|---|---|---|---|---|---|
| 55 | 400 | 11×23 | 115 | 50 | B | THG100151 | THW100025 | THC100026 |
If the parameter is not suitable for you, please contact us. Our professional team can provide technical knowledge and drawings.
We advise customers on selecting the right heat lamp for specific applications. Our Technical Department can design lamps based on your technical specifications.
We produce various sizes and types of heat lamps according to customer requirements. Providing drawings is ideal for sample production.
Provide your required lamp specifications (type, diameter, length, power, voltage, reflector). We'll send a quotation. After payment, production begins and products ship when complete.
Our emitters can be coated with gold or ceramic reflectors to concentrate heat and increase efficiency. For high watt density or temperatures above 800°C, we recommend ceramic coating (resistant to 1000°C). Custom coating degrees available.
Yes, we provide mounting clamps corresponding to purchased lamps at no additional cost.
Send drawings, sketches, or samples for quotation. We specialize in custom designs and small runs while remaining competitive on large orders.
Quality is our priority. We maintain strict QC from material procurement to final packaging. Our products are certified CE, ROHS, and ISO9001 compliant.
